Archive Garage

2005-2023 Tacoma Traveler Add-A-Leaf AAL (stock springs)

2005-2023 Tacoma Traveler Add-A-Leaf AAL (stock springs)

$175.00 USD

LEAD TIME: IN STOCK

Adding armor, hauling or towing? Archive's Traveler Leaf is specifically designed to enhance stock 2005-2023 Tacoma leaf spring packs.

The Traveler leaf:

  • Improves load handling, combats squat
  • Increases spring rate and retains overload leaf
  • Fits 3+1 without any modification unlike competition!
  • Creates attractive 4+1 pack from stock leaf packs
  • Fits using stock Tacoma 6.5" U-bolts (check condition)
  • Added spring rate and lift keeps you off the rear bump stops.
  • We highly recommend our Hammer Hangers for best ride and handling!

Specs:

  • Made in USA with American 5160 steel! (NOT India or China)
  • Approximate 1" lift  (~9.25" top of axle tube to frame bot.) w/ 500 lbs added to DCSB axle weight**
  • Approximate 2" lift  (~10.25" top of axle tube to frame bot.) w/ no weight on DC 4-door
  • Intended load: 200 to 750 lbs added to rear axle weight** on DC 4-door
  • Diamond cut ends, tip inserts, and black painted finish
  • Leaf material width: 60mm (2.375") to match stock leaves
  • Leaf spring travel: same as stock (uses ~10" shock travel)
  • Ride with no weight (w/ Hammer Hangers + Fox 2.5"): firmer spring rate is noticed, however still smooth.
  • Ride with 500lbs added (w/ Hammer Hangers + Fox 2.5"): nice ride and confident handling
